Paper jam in Tray 1

1 Open Tray 1.

2 Firmly grasp the jammed paper on each side, and then gently pull it out.

3 Close Tray 1.

4 If necessary, touch Continue, jam cleared from the printer control panel.

Clearing jams 281
