Dead printer service check
A dead printer is one which, when powered on from a known good electrical outlet, displays no indication of power to
the printer by changes to the LCD, LED, or any movement of the fan or motors. If the printer appears dead but makes
a beeping sound, check the operator panel. See
“Operator panel (displays all diamonds, no beeps, or five beeps)
service check” on page 131.
If a 650-sheet Duo Drawer is installed, then remove the option and check the base printer for correct operation. If the
base printer operates correctly, replace the 650-sheet Duo Drawer.
Warning—Potential Damage: Observe all necessary ESD precautions when removing and handling the controller
board or any installed option cards or assemblies.
CAUTION—SHOCK HAZARD: When you see this symbol, there is a danger from hazardous voltage in the area of
the product where you are working. Unplug the product before you begin, or use caution if the product must
receive power to perform the task.
Note: Remove any input paper-handling options from the printer.
Actions Yes No
Step 1
Check the AC power voltage.
Is the line voltage correct?
Go to step 2. There may be issues
with the line voltage.
Inform the customer.
Step 2
Is the AC power cord damaged?
Replace the power
cord.
Go to step 3.
Step 3
Are the USB ground contacts attached to the USB connections on the
controller board and controller board cage?
Go to step 5. Go to step 4.
Step 4
Install the USB ground contacts in the controller board.
Did this fix the problem?
Problem solved. Go to step 5.
7527
Diagnostic information
121
