Lexmark XC2132 Service Manual

Actions Yes No
Step 13
Check the device that cannot receive a fax.
Can it send a fax?
Go to step 14. Stop here. The issue is
with the other device.
Step 14
Press **411 to enter the Fax/SE Menu. Select “Print Logs”.
Print the T30 transmission log. Check the error being reported with the
fax error code table. See
“Fax error log codes” on page 156.
Perform the suggested resolution for the error.
Did this fix the problem?
Problem resolved. Go to step 15.
Step 15
Adjust the “Transmit Level” setting in the SE menu. press **411 to enter
the SE menu, enter Modem settings, and select “Transmit Level”.
Test by adjusting the transmitted signal strength by decreasing/increasing
the ‘Transmit Level’ setting in steps of 1db. For example, if default value
is -11 db, changing it to-12db will decrease the signal strength by 1db, and
changing it to -10db will increase the signal strength by 1db.
Recommended adjustment range is ±5 db (in 1db steps) from the default
value.
Did this fix the problem?
Stop. Problem
resolved.
Go to yo ur s ec on d- le vel
of support. See
“Escalating a fax issue
to second‑level
support” on page 160.
Fax transmission service check
Actions Yes No
Step 1
Is the phone line properly connected to the modem card and the wall jack?
Go to step 2. Go to step 3.
Step 2
Properly connect the phone line to the modem card and wall jack.
Did this fix the problem?
Problem resolved Go to step 3.
Step 3
Check for a dial tone.
Is there a dial tone?
Go to step 4. Go to step 6.
Step 4
Use a telephone to test the phone line’s ability to send and receive calls.
Did the phone line work properly?
Go to step 7. Go to step 5.
7527
Diagnostic information
154

Lexmark XC2132 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	10.5 s
Time to first page (color, normal)	11.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	copy, print
Digital sender	No
Maximum duty cycle	85000 pages per month
Recommended duty cycle	1500 - 7000 pages per month
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Time to first copy (black, normal)	10.8 s
Time to first copy (color, normal)	11.6 s
Copy speed (black, normal quality, A4)	30 cpm
Scanner type	Flatbed & ADF scanner
Optical scanning resolution	600 x 1200 DPI
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum print size	210 x 297 mm
Paper tray media types	Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Control type	Touch
Product color	Grey, White
Display diagonal	7 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Internal memory	1024 MB
Card reader integrated	-
Maximum internal memory	3072 MB
Sound pressure level (copying)	50 dB
Sound pressure level (scanning)	49 dB
Power consumption (average operating)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	589 mm
Width	444 mm
Height	470 mm
