Lexmark XC2132 Service Manual

Actions Yes No
Step 7
Replace the ADF. See
“ADF assembly removal” on page 326.
Does this fix the situation?
Problem solved. Replace the controller
board. See
“Controller
board removal” on
page 309.
Modem/fax card service check
Note: This service check should be used if the paper feeds and jams in the ADF. If the paper is not feeding into the
ADF see
“ADF feed errors service check” on page 148.
Actions Yes No
Step 1
Is the phone line properly connected to the modem card and the wall jack?
Go to step 2. Go to step 3.
Step 2
Properly connect the phone line to the modem card and wall jack.
Did this fix the problem?
Problem resolved. Go to step 3.
Step 3
Test the phone line’s ability to send and receive calls.
Did the phone line work properly?
Go to step 5. Go to step 4.
Step 4
Use the MFP on a properly functioning phone jack.
Did this fix the problem?
Problem resolved. Go to step 5.
Step 5
Is the modem card ribbon cable properly connected to the system board
at JMOD2 and the modem card?
Go to step 7. Go to step 6.
Step 6
Properly connect the modem card cable to the modem card and system
board.
Did this fix the problem?
Problem resolved. Go to step 7.
Step 7
Check the modem card ribbon cable for continuity.
Is there continuity?
Go to step 8. Replace the modem
card cable.
7527
Diagnostic information
151

Lexmark XC2132 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	10.5 s
Time to first page (color, normal)	11.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	copy, print
Digital sender	No
Maximum duty cycle	85000 pages per month
Recommended duty cycle	1500 - 7000 pages per month
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Time to first copy (black, normal)	10.8 s
Time to first copy (color, normal)	11.6 s
Copy speed (black, normal quality, A4)	30 cpm
Scanner type	Flatbed & ADF scanner
Optical scanning resolution	600 x 1200 DPI
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum print size	210 x 297 mm
Paper tray media types	Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Control type	Touch
Product color	Grey, White
Display diagonal	7 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Internal memory	1024 MB
Card reader integrated	-
Maximum internal memory	3072 MB
Sound pressure level (copying)	50 dB
Sound pressure level (scanning)	49 dB
Power consumption (average operating)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	589 mm
Width	444 mm
Height	470 mm
