Lexmark XC2132 Service Manual

Symptom Action
Printout is skewed. Go to
“Double feed and printout skewed service check” on page 166.
Failed to feed from input option tray. Go to
“Failed to feed from option tray and leading edge damaged service
check” on page 171.
Leading edge damaged. Go to
“Failed to feed from option tray and leading edge damaged service
check” on page 171.
Failed to feed from multipurpose feeder. Go to
“Failed to load/feed from multipurpose feeder service check” on
page 168.
Load multipurpose feeder with plain paper
letter.
Go to
“Failed to load/feed from multipurpose feeder service check” on
page 168.
Paper input tray missing (tray 2 or tray 3). Go to
“Tray 2 or tray 3 missing service check” on page 176.
Tray 2 or tray 3 not detected. Go to
“Tray 2 or tray 3 not detected service check” on page 173.
Input option tray 2 or 3 empty. Go to
“Tray 2 or tray 3 empty service check” on page 178.
Incompatible tray 3. Go to
“Incompatible tray 3 service check” on page 181.
Tray (x) sensor service check
Actions Yes No
Step 1
a POR the printer.
b Reseat the printer from the input option. Make sure it is installed
correctly.
c Make sure the input option configuration is supported for that printer.
Refer to the Input Option Configuration Guide.
Does the error remain?
Go to step 2. Problem resolved.
Step 2
When the printer is in Ready state, pull the standard tray out. The display
should indicate Tray (x) Missing. Reinsert the tray.
Does the message remain on the display?
Go to step 3. Go to step 5.
Step 3
Check the vertical wall at the right rear of the tray for damage.
Is the tray damaged?
Replace the tray. Go to step 4.
7527
Diagnostic information
162

Lexmark XC2132 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	10.5 s
Time to first page (color, normal)	11.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	copy, print
Digital sender	No
Maximum duty cycle	85000 pages per month
Recommended duty cycle	1500 - 7000 pages per month
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Time to first copy (black, normal)	10.8 s
Time to first copy (color, normal)	11.6 s
Copy speed (black, normal quality, A4)	30 cpm
Scanner type	Flatbed & ADF scanner
Optical scanning resolution	600 x 1200 DPI
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum print size	210 x 297 mm
Paper tray media types	Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Control type	Touch
Product color	Grey, White
Display diagonal	7 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Internal memory	1024 MB
Card reader integrated	-
Maximum internal memory	3072 MB
Sound pressure level (copying)	50 dB
Sound pressure level (scanning)	49 dB
Power consumption (average operating)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	589 mm
Width	444 mm
Height	470 mm
