OCCUPANT RESTRAINT SYSTEMS

159

16L262a

"

Upper lumbar support

Push the upper lumbar support control switch on either

side.

The amount of upper lumbar support will change while the

switch is pushed.

Front passenger’s seat

16L354a

Push the control switch on either side.

The amount of lumbar support will change while the switch is

pushed.
