6-3. Do-it-yourself maintenance
6
Maintenance and care
3 Remove the fuse.
Only type A fuse can be removed using
the pullout tool.
4 Check if the fuse is blown.
Replace the blown fuse with a new fuse of
an appropriate amperage rating. The
amperage rating can be found on the fuse
box lid.
 Type A
Normal fuse
Blown fuse
 Type B
Normal fuse
Blown fuse
 Type C
Normal fuse
Blown fuse
 Type D
Normal fuse
Blown fuse
A
B
A
B
A
B
A
B
