3. Grab the knob and move the Pressure Adjustment to change the punch pressure.
3.1 Note: Move the Pressure Adjustment down to lower the Upper Punch and increase
the punch pressure. Move the Pressure Adjustment up to raise the Upper Punch
and decrease the punch pressure.
3.2 Note: If there is no more room for adjustment but there still needs to be increased
pressure, remove the adjustment knob by fully turning it counterclockwise and insert it into
the next hole above and continue to gradually increase the pressure.
CAUTION: Applying too much pressure can damage the machine and/or
Tooling.
4. Tighten the Pressure Adjustment Knob by turning it clockwise to set the adjustment.
