TDP 6s

Parts List

1. Lower Drift Pin Assembly Timing Cam (#AFC0052)

2. Top Cam Drive Shaft (#AFC0037)

3. Eccentric Sheave/Pressure Adjustment (#AFC0004)

4. Hand Wheel (under safety cover) (#AFC0058)

5. Boot Timing Cam (#AFC0038)

6. Boot Timing Bar (#AFC0018)

7. Boot (#AEC0036)

8. Boot Bolt and Spring (#AEC0051)

9. Electric Motor (#AFC0042)

10. Lower Drift Pin Assembly (#AEC0011)

11. Lower Drift Pin Assembly Locking Bar (#AEC0013)

12. Base Plate (#AFC0008)

13. Ejection Tray (#AEC0049)

14. Hopper (#AEC0030)

15. Cam Drive Cog (#AFC0050)

16. Lower Drift Pin Assembly Cogs (#AEC0012)

17. Lower Assembly Timing Rod (#AFC0014)

18. Upper Drift Pin Assembly (#AFC0002)
