LG 22MP56HQ User Manual

17
ENG
ENGLISH
CUSTOMIZING SETTINGS
READERSetting
1
 Press
READER
buttonontherearoftheMonitorset
todisplaythe
ReaderMode
OSD.
2
 Settheoptionsbypressingthe◄buttons.
ReaderMode
Description
Reader1 Itisamodethatthescreenisadjustedtothebestforthenewspaper.Ifyou
wantscreenmorebright,youcancontrolbrightnessinMenuOSD.
Reader2 Itisamodethatthescreenisadjustedtothebestforthecartoon.Ifyouwant
screenmorebright,youcancontrolbrightnessinMenuOSD.
ReaderOff Itisamodethatreadermodeisoff.
Eachoptionisexplainedbelow.

NOTE
IfoptionofReaderModeisReader1orReader2,PictureModewillautomaticallybeCustomand
SUPERENERGYSAVINGwillautomaticallybeOff.

LG 22MP56HQ Specifications

General

3D	-
DDC/CI	Yes
Panel type	AH-IPS
Pixel pitch	0.24795 x 0.24795 mm
Aspect ratio	16:9
Display diagonal	22 \
Display technology	LED
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Supported video modes	1080p
Contrast ratio (dynamic)	5000000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
USB Type-A downstream ports quantity	0
Certification	TC06.0, EPA 6.0, FCC-B, CE, UL(cUL)
Product color	Black, Silver
LED indicators	Power
Tilt angle range	-5 - 20 °
Panel mounting interface	75 x 75 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	20 W
Sustainability certificates	EPEAT Gold
Package depth	371 mm
Package width	579 mm
Package height	123 mm

Weight and Dimensions

Depth (with stand)	188 mm
Height (with stand)	411 mm
Weight (with stand)	4600 g
Depth (without stand)	59 mm
Width (without stand)	509 mm
Height (without stand)	304 mm
Weight (without stand)	4300 g
