OPTIONAL OPERATION
ENGLISH
Installer Setting -Ceiling Height Selection
This function is to adjust FAN Airflow rate according to ceilingheight (only cassette model)
Function Code Thermistor setting
Select ceiling height value by pressing
button. (01:Low, 02:Standard,
03:High, 04Very high)
3
Press button to save.
4
5
If moving to ceiling height selection menu by
pressing button, it indicates as picture below.
2
If pressing button long for 3
seconds, it enters into remote controller
setter setup mode.
- If pressing once shortly, it enters into
user setup mode. Please press more
than 3 seconds for sure.
1
Pressing button will exit settings mode.
❈ After setup, it automatically gets out of setup
mode if there is no button input for 25
seconds.
❈ When exiting without pressing set button, the
manipulated value is not reflected.
<Ceiling Height Selection Table>
* Ceiling height setting is available only for some products.
* Ceiling height of ‘Super high’ function may not exist depending on the indoor unit.
* Refer to the product manual for more details.
Ceiling Height Level Description
01 Low Decrease the indoor airflow rate 1 step from standard level
02 Standard Set the indoor airflow rate as standard level
03 High Increase indoor airflow rate 1 step from standard level
04 Super high Increase indoor airflow rate 2 steps from standard level
