DRYER
ACCESSORIES
DRYING RACK STACKING KIT PEDESTAL
The DRYING RACK is used to dry items that should not be tumbled, like
sweaters, tennis shoes, etc. It should be removed and stored when not in use.
The rack is included with the dryer. (See installation procedure, page xx.)
The STACKING KIT is used to stack a dryer on top of a matching washer.
(NEVER put a washer on top of a dryer!) The stacking kit should not be used in
situation where there is the possibility of excessive vibration and movement of
the washer, such as in a mobile home or an upper floor of a frame structure. The
stacking kit is available as an optional purchase. (See installation procedure,
page 11.)
The PEDESTAL can be used under either the washer or the dryer. It is possible
to stack a washer and dryer on a pedestal, but the dryer controls may be difficult
to reach and the possibility of vibration and movement is greater. The pedestal is
available as an optional purchase. (See installation procedure, page 13.)
Pedestals are available in heights of 7¼” and 13”.
INSTALLATION (RACK)
It’s simple!
Open the dryer door.
Put the rack in place.
Select RACK DRY (2
nd
button on right)
Press START.
Be sure the front of the rack is properly
situated in the notches on either side
of the filter. The back should rest on
the drum and allow the drum to rotate.
DLE8377xM/DLG8388xM
DLE7177WM/DLE7188WM Page 10 of 60 TRAINING MANUAL
