DRYER
FRONT CABINET
1. Remove the top plate.
2. Remove the control panel.
3. Remove the door, if necessary
for the repair.
4. Remove two screws in the
bottom of the door opening.
5. Remove four screws from the
top of the front cabinet.
6. Tilt the front away from the dryer
and disconnect the door switch
wire harness.
DOOR REVERSAL
1. Remove two screws that hold
the door. Remove the door and
set it aside on a soft, protective
cloth. Save the hinge shim.
2. Remove two screws near the
latch.
3. Remove two screws and the
latch piece.
4. Rotate everything 180° and
reinstall so the door opens from
the other side.
DLE8377xM/DLG8388xM
DLE7177WM/DLE7188WM Page 45 of 60 TRAINING MANUAL
