DRYER
ROLLERS
1. Remove the top plate.
2. Remove the front cover.
3. Remove the tub front.
4. Remove the drum (if replacing
the back rollers.)
5. Use an open-end wrench to
remove and replace the shaft
and roller.
NOTE:
If the shaft is OK and you are replacing
only the roller, you can squeeze the
triangular retainer to remove and
replace the roller without removing the
shaft from the machine.
Be sure to install the small bushings.
These must be between the roller and
the retainer on both sides of the roller.
See photo.
DLE8377xM/DLG8388xM
DLE7177WM/DLE7188WM Page 51 of 60 TRAINING MANUAL
