LG DLE8377CM Training Manual

DRYER
PARTS LIST
DLE8377xM/DLG8388xM
DLE8377NM DLE8377WM DLG8388NM DLG8388WM
Loc Description
Part No Part No Part No Part No
*001 Owner's Manual 3829EL3009B 3829EL3009B 3829EL3009B 3829EL3009B
*002 Box, Carton 3890EZ3613A 3890EZ3613A 3890EZ3613A 3890EZ3613A
*004 Manual, Service 3828EL3005D 3828EL3005D 3828EL3005D 3828EL3005D
A110 Panel Assembly, Control 3721EL0009C 3721EL0009A 3721EL0009D 3721EL0009B
A120 PCB Assembly, Display 6871EL1011A 6871EL1011A 6871EL1011B 6871EL1011B
A130 PCB Assembly, Main 6871EL1013C 6871EL1013C 6871EL1013D 6871EL1013D
A140 Knob Assembly 4941ER3005A 4941ER3005A 4941ER3005A 4941ER3005A
A210 Plate Assembly, Top 3457ER1006X 3457ER1006D 3457ER1006X 3457ER1006D
A211 Plate, Upper 3300EL2001E 3300EL2001A 3300EL2001E 3300EL2001A
A300 Bracket, Hinge 4810EL3006A 4810EL3006A 4810EL3006A 4810EL3006A
A305 Bracket, Hinge 4810EL3006B 4810EL3006B 4810EL3006B 4810EL3006B
A310 Cabinet Cover Assembly 3551EL0009B 3551EL0009A 3551EL0009B 3551EL0009A
A320 Locker Assembly 4027EL1001A 4027EL1001A 4027EL1001A 4027EL1001A
A330 Switch, Micro 6601EL3001A 6601EL3001A 6601EL3001A 6601EL3001A
A330 Safety Switch Assembly 6601EL3001A 6601EL3001A 6601EL3001A 6601EL3001A
A390 Frame Assembly 3211EL1004A 3211EL1004A 3211EL1004A 3211EL1004A
A400 Door Assembly 3581EL0004A 3581EL0004A 3581EL0004A 3581EL0004A
A410 Locker, Hook 4026EL3007A 4026EL3007A 4026EL3007A 4026EL3007A
A420 Outer Door Frame 3212EL1015A 3212EL1015A 3212EL1015A 3212EL1015A
A430 Hinge 4774EL2001A 4774EL2001A 4774EL2001A 4774EL2001A
A450 Inner Door Frame 3212EL1005B 3212EL1005B 3212EL1005B 3212EL1005B
A460 Gasket 4986EL2004A 4986EL2004A 4986EL2004A 4986EL2004A
A500 Cabinet Assembly 3091EL0003P 3091EL0003M 3091EL0003Q 3091EL0003N
A510 Cap (Knockout cover) 5006EL3001G 5006EL3001D 5006EL3001G 5006EL3001D
A520 Bracket, Base 4810EL3001A 4810EL3001A 4810EL3001A 4810EL3001A
A525 Bracket, Base 4810EL3009A 4810EL3009A 4810EL3009A 4810EL3009A
A530 Bracket, Base 4810EL3009B 4810EL3009B 4810EL3009B 4810EL3009B
A540 Leg 4778EL3001A 4778EL3001A 4778EL3001A 4778EL3001A
A560 Cover, Guide 3550EL3007A 3550EL3007A 6411ER1005B 6411ER1005B
A570 Cover, Safety 3550EL3002A 3550EL3002A
A600 HARNESS, PWB 6877EL1019B 6877EL1019B 6877EL1020B 6877EL1020B
A700 Rack 3750EL1001B 3750EL1001B 3750EL1001B 3750EL1001B
A800 Parts As’by
(Side Vent Kit) 383EEL9001B 383EEL9001B 383EEL9001B 383EEL9001B
F110 Heater Assembly (Elec) 5301EL1001G 5301EL1001G
F120 Bracket, Heater 4810EL1007A 4810EL1007A
F130 Thermostat 6931EL3003D 6931EL3003D
F140 Thermostat Assembly 6931EL3001E 6931EL3001E
F200 Duct Assembly 5209EL1001C 5209EL1001C 5209EL1001D 5209EL1001D
K100 Tub Assembly, Drum 3045EL1002E 3045EL1002E 3045EL1002E 3045EL1002E
K120 Lifter 4432EL1002B 4432EL1002B 4432EL1002B 4432EL1002B
K130 Belt, Poly V 4400EL2001A 4400EL2001A 4400EL2001A 4400EL2001A
DLE7177WM/DLE7188WM Page 57 of 60 TRAINING MANUAL
