DRYER
ELECTRICAL CONNECTION (Electric Dryer Only) continued
Be sure to tighten all screws firmly, but
do not strip them or distort the contact
area.
Be sure to install a strain relief on the
power cord.
Replace the terminal block cover by
inserting the tabs into the slots and
letting them slide down to engage.
Fold it over to the back of the dryer so
it covers the access to the terminal
block. Be sure no wires are exposed or
could touch any metal surface.
Secure the cover with a screw.
DLE8377xM/DLG8388xM
DLE7177WM/DLE7188WM Page 18 of 60 TRAINING MANUAL
