LG HB620 Service Manual

LGE Internal Use Only Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
11. EXPLODED VIEW & REPLACEMENT PART LIST
- 193 -
Level
Location
No.
Description Part Number Spec Color
Remark
6 FL507 FILTER,EMI/POWER SFEY0013501 SMD ,18V,4ch. EMI_ESD Filter (10 Ohm,7.5pF)
6 FL701 FILTER,EMI/POWER SFEY0015301 SMD ,Pb-free_Bais ,; ,Filter,LCR
6J401 CONN,SOCKET ENSY0019201 8 PIN,ETC ,8Pin ,2.54 mm,Korean 8Pin Stopper UIM
6L102 CAP,CHIP,MAKER ECZH0000802 1 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP
6L103 INDUCTOR,CHIP ELCH0004701 12 nH,J ,1005 ,R/TP ,
6L104 INDUCTOR,CHIP ELCH0003825 56 nH,J ,1005 ,R/TP ,chip inductor,PBFREE
6L105 INDUCTOR,CHIP ELCH0001036 5.6 nH,S ,1005 ,R/TP ,PBFREE
6L106 INDUCTOR,CHIP ELCH0005018 39 nH,J ,1005 ,R/TP ,
6L107 INDUCTOR,CHIP ELCH0005005 27 nH,J ,1005 ,R/TP ,
6L108 INDUCTOR,CHIP ELCH0001036 5.6 nH,S ,1005 ,R/TP ,PBFREE
6L109 INDUCTOR,CHIP ELCH0005015 6.8 nH,S ,1005 ,R/TP ,
6L111 INDUCTOR,CHIP ELCH0005003 12 nH,J ,1005 ,R/TP ,
6L112 INDUCTOR,CHIP ELCH0003813 47 nH,J ,1005 ,R/TP ,COIL TYPE
6L113 INDUCTOR,CHIP ELCH0005015 6.8 nH,S ,1005 ,R/TP ,
6L114 INDUCTOR,CHIP ELCH0005005 27 nH,J ,1005 ,R/TP ,
6L116 INDUCTOR,CHIP ELCH0005005 27 nH,J ,1005 ,R/TP ,
6L117 INDUCTOR,CHIP ELCH0005005 27 nH,J ,1005 ,R/TP ,
6L118 INDUCTOR,CHIP ELCH0003813 47 nH,J ,1005 ,R/TP ,COIL TYPE
6L119 INDUCTOR,CHIP ELCH0005020 1 nH,S ,1005 ,R/TP ,
6L120 INDUCTOR,CHIP ELCH0003813 47 nH,J ,1005 ,R/TP ,COIL TYPE
6L121 INDUCTOR,CHIP ELCH0001040 3.9 nH,S ,1005 ,R/TP ,PBFREE
6L122 CAP,CHIP,MAKER ECZH0000802 1 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP
6L123 CAP,CHIP,MAKER ECZH0001002 0.5 pF,50V ,B ,NP0 ,TC ,1005 ,R/TP
6L124 INDUCTOR,CHIP ELCH0001403 1 nH,S ,1005 ,R/TP ,PBFREE
6L125 CAP,CERAMIC,CHIP ECCH0000185 5.6 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP
6L401 INDUCTOR,SMD,POWER ELCP0008004
4.7 uH,M ,1 ,R/TP , ,; , ,0.3NH , , , , , ,NON SHIELD
,2.5X2X1MM ,11MM ,R/TP
6L402 INDUCTOR,SMD,POWER ELCP0008004
4.7 uH,M ,1 ,R/TP , ,; , ,0.3NH , , , , , ,NON SHIELD
,2.5X2X1MM ,11MM ,R/TP
6L403 INDUCTOR,SMD,POWER ELCP0008004
4.7 uH,M ,1 ,R/TP , ,; , ,0.3NH , , , , , ,NON SHIELD
,2.5X2X1MM ,11MM ,R/TP
6L404 INDUCTOR,CHIP ELCH0001529 56 nH,J ,1608 ,R/TP ,PBFREE
6 L501 INDUCTOR,CHIP ELCH0001022 56 nH,J ,1005 ,R/TP ,Pb Free
6 L701 INDUCTOR,CHIP ELCH0001430 100 nH,J ,1005 ,R/TP ,PBFREE
6L801 INDUCTOR,SMD,POWER ELCP0008003 3.3 uH,M ,2.5*2.0*1.0 ,R/TP ,Chip power
6L900 INDUCTOR,SMD,POWER ELCP0008004
4.7 uH,M ,1 ,R/TP , ,; , ,0.3NH , , , , , ,NON SHIELD
,2.5X2X1MM ,11MM ,R/TP
6 M701 MODULE,ETC SMZY0017601
QCT RF Module 3.85x3.8x1.2 ,; ,Bluetooth
