11. EXPLODED VIEW & REPLACEMENT PART LIST
- 194 -
Level
Location
No.
Description Part Number Spec Color
Remark
6 MIC301 MICROPHONE SUMY0010604
UNIT ,-38 dB,4.72*3.76 ,1.25T Bottom Silicon type ,; , ,
,UNI ,1.5V , ,SMD
6R1002 RES,CHIP ERHY0003201 1000 ohm,1/16W ,F ,1005 ,R/TP
6R102 RES,CHIP,MAKER ERHZ0000212 12 Kohm,1/16W ,F ,1005 ,R/TP
6R103 RES,CHIP,MAKER ERHZ0000310 680 ohm,1/16W ,F ,1005 ,R/TP
6R106 RES,CHIP,MAKER ERHZ0000402 10 ohm,1/16W ,J ,1005 ,R/TP
6R107 RES,CHIP,MAKER ERHZ0000443 2200 ohm,1/16W ,J ,1005 ,R/TP
6R108 RES,CHIP,MAKER ERHZ0000504 68 ohm,1/16W ,J ,1005 ,R/TP
6R109 RES,CHIP,MAKER ERHZ0000517 91 ohm,1/16W ,J ,1005 ,R/TP
6R110 RES,CHIP,MAKER ERHZ0000517 91 ohm,1/16W ,J ,1005 ,R/TP
6R112 RES,CHIP,MAKER ERHZ0000490 51 ohm,1/16W ,J ,1005 ,R/TP
6R114 RES,CHIP,MAKER ERHZ0000411 120 ohm,1/16W ,J ,1005 ,R/TP
6R115 RES,CHIP,MAKER ERHZ0000411 120 ohm,1/16W ,J ,1005 ,R/TP
6R116 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
6R119 RES,CHIP,MAKER ERHZ0000490 51 ohm,1/16W ,J ,1005 ,R/TP
6 R120 RES,CHIP,MAKER ERHZ0000490 51 ohm,1/16W ,J ,1005 ,R/TP
6 R121 RES,CHIP,MAKER ERHZ0000411 120 ohm,1/16W ,J ,1005 ,R/TP
6 R122 RES,CHIP,MAKER ERHZ0000411 120 ohm,1/16W ,J ,1005 ,R/TP
6 R201 RES,CHIP,MAKER ERHZ0000407 1000 Kohm,1/16W ,J ,1005 ,R/TP
6 R202 RES,CHIP,MAKER ERHZ0000288 470 Kohm,1/16W ,F ,1005 ,R/TP
6 R203 RES,CHIP,MAKER ERHZ0000222 150 Kohm,1/16W ,F ,1005 ,R/TP
6 R205 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
6 R206 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
6 R207 RES,CHIP,MAKER ERHZ0000490 51 ohm,1/16W ,J ,1005 ,R/TP
6 R208 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
6 R211 RES,CHIP,MAKER ERHZ0000437 2 Kohm,1/16W ,J ,1005 ,R/TP
6 R212 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
6 R213 RES,CHIP,MAKER ERHZ0000443 2200 ohm,1/16W ,J ,1005 ,R/TP
6 R214 RES,CHIP,MAKER ERHZ0000443 2200 ohm,1/16W ,J ,1005 ,R/TP
6 R215 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
6R301 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
6R302 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
6R303 RES,CHIP,MAKER ERHZ0000405 10 Kohm,1/16W ,J ,1005 ,R/TP
6R304 RES,CHIP,MAKER ERHZ0000401 0 ohm,1/16W ,J ,1005 ,R/TP
6R305 RES,CHIP,MAKER ERHZ0000404 1 Kohm,1/16W ,J ,1005 ,R/TP
6R306 RES,CHIP,MAKER ERHZ0000431 18 Kohm,1/16W ,J ,1005 ,R/TP
6R307 RES,CHIP,MAKER ERHZ0000404
1 Kohm,1/16W ,J ,1005 ,R/TP
