LG HB620 Service Manual

LGE Internal Use Only Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
11. EXPLODED VIEW & REPLACEMENT PART LIST
- 195 -
Level
Location
No.
Description Part Number Spec Color
Remark
6 R308 RES,CHIP,MAKER ERHZ0000431 18 Kohm,1/16W ,J ,1005 ,R/TP
6 R309 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
6R311
PCB ASSY,MAIN,PAD
SHORT
SAFP0000501
6 R401 RES,CHIP,MAKER ERHZ0000288 470 Kohm,1/16W ,F ,1005 ,R/TP
6 R402 RES,CHIP,MAKER ERHZ0000487 470 Kohm,1/16W ,J ,1005 ,R/TP
6 R403 RES,CHIP,MAKER ERHZ0000318 80.6 Kohm,1/16W ,F ,1005 ,R/TP
6 R404 RES,CHIP,MAKER ERHZ0000537 680000 ohm,1/16W ,F ,1005 ,R/TP
6 R405 RES,CHIP,MAKER ERHZ0004201 121000 ohm,1/16W ,F ,1005 ,R/TP
6 R406 RES,CHIP,MAKER ERHZ0000203 10 Kohm,1/16W ,F ,1005 ,R/TP
6 R407 RES,CHIP,MAKER ERHZ0000490 51 ohm,1/16W ,J ,1005 ,R/TP
6 R408 RES,CHIP ERHY0000275 56K ohm,1/16W,J,1005,R/TP
6 R409 RES,CHIP,MAKER ERHZ0000486 47 Kohm,1/16W ,J ,1005 ,R/TP
6R410 RES,CHIP ERHY0000275 56K ohm,1/16W,J,1005,R/TP
6R412 RES,CHIP,MAKER ERHZ0004301 0.1 ohm,1/4W ,F ,ETC ,R/TP
6R413 RES,CHIP,MAKER ERHZ0000485 4700 ohm,1/16W ,J ,1005 ,R/TP
6R416 RES,CHIP,MAKER ERHZ0000405 10 Kohm,1/16W ,J ,1005 ,R/TP
6 R501 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
6 R502 RES,CHIP,MAKER ERHZ0000483 47 ohm,1/16W ,J ,1005 ,R/TP
6 R503 RES,CHIP,MAKER ERHZ0000493 51 Kohm,1/16W ,J ,1005 ,R/TP
6 R702 RES,CHIP,MAKER ERHZ0000443 2200 ohm,1/16W ,J ,1005 ,R/TP
6 R703 RES,CHIP,MAKER ERHZ0000504 68 ohm,1/16W ,J ,1005 ,R/TP
6 R704 RES,CHIP,MAKER ERHZ0000504 68 ohm,1/16W ,J ,1005 ,R/TP
6 R705
PCB ASSY,MAIN,PAD
SHORT
SAFP0000501
6 R706
PCB ASSY,MAIN,PAD
SHORT
SAFP0000501
6 R800 RES,CHIP,MAKER ERHZ0000407 1000 Kohm,1/16W ,J ,1005 ,R/TP
6 R803 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
6R813
PCB ASSY,MAIN,PAD
SHORT
SAFP0000501
6R814 RES,CHIP,MAKER ERHZ0000405 10 Kohm,1/16W ,J ,1005 ,R/TP
6R815 RES,CHIP ERHY0000147 56K ohm,1/16W,F,1005,R/TP
6R816 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
6R817 RES,CHIP ERHY0000147 56K ohm,1/16W,F,1005,R/TP
6R818 RES,CHIP ERHY0000254 4.7K ohm,1/16W,J,1005,R/TP
6R819 RES,CHIP ERHY0000254 4.7K ohm,1/16W,J,1005,R/TP
6 R830
PCB ASSY,MAIN,PAD
SHORT
SAFP0000501
