102
Instalação do Hardware Etapa pela Etapa (Versão de VGA)
1. Gire seu LCD oposto a com cuidado que pode ver todo o porto da conexão.
2. Inserir o cabo do sinal tal como o analog do RGB a seu próprio porto, e o outro lado conectam ao
computador.
3. Inserir o conector audio a seu próprio porto, e o outro lado conectam à linha de computador para fora.
4. Ponha adaptador de AC e cordão de poder junto.
5. Inserir o cabo da DC a seu próprio porto.O outro lado conecta ao soquete, gira sobre o poder.
6. Felicitações que você tinha feito com ele. Você pode apreciar o desempenho excelente.

Table of Contents

Other manuals for LG L1718S

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LG L1718S and is the answer not in the manual?

LG L1718S Specifications

Display IconDisplay
display type17.0" Active Matrix TFT LCD Screen
display area13.3" x 10.6" (338mm x 270mm)
display colors16.2 Million
maximum resolution1280 x 1024
pixel configurationRGB Stripe Arrangement
surface treatmentHard Coating 3H, Anti-Glare
View and Performance IconView and Performance
brightness300cd/m2
contrast ratio700:1
response time8ms
pixel pitch0.264mm x 0.264mm
viewing angleH: 160 Deg., V: 160 Deg.
Power IconPower
power requirements90 ~ 264 Vac / 47.5 ~ 63 Hz
dpms power consumption on35 Watts
dpms power consumption standby1 Watts
Physical Characteristics IconPhysical Characteristics
dimensions with base14.8" x 7.1" x 14.9" (375mm x 180mm x 380mm)
weight set8.2 lbs.
weight shipping10.6 lbs.
tilt/swivelTilt: Forward 5° / Backward 20° (No Swivel)
vesa mounting compliance75mm x 75mm Screw Spacing
