Adjustando o Monitor
Botões de controle do Menu
Introdução dos botões
Power: Liga e desliga o LCD. Quando ligado, acende a luz verde e quando em “stand by” a mesma se torna
laranja.
Menu OSD: Pressione o botão do menu OSD, ajuste do menu direito.
Auto Tune: Auto ajuste, ajuste do menu esquerdo.
Decrease < - >: Diminue o valor da opção no menu OSD.
Increase < + >: Muda o ambiente de operação do VGA para DVI. Aumenta o valor da opção no menu OSD.
Menu OSD
Diminuir < - >
Aumentar
<+>
Força
Auto Tune

LG L1718S Specifications

Display

display type	17.0" Active Matrix TFT LCD Screen
display area	13.3" x 10.6" (338mm x 270mm)
display colors	16.2 Million
maximum resolution	1280 x 1024
pixel configuration	RGB Stripe Arrangement
surface treatment	Hard Coating 3H, Anti-Glare

View and Performance

brightness	300cd/m2
contrast ratio	700:1
response time	8ms
pixel pitch	0.264mm x 0.264mm
viewing angle	H: 160 Deg., V: 160 Deg.

Power

power requirements	90 ~ 264 Vac / 47.5 ~ 63 Hz
dpms power consumption on	35 Watts
dpms power consumption standby	1 Watts

Physical Characteristics

dimensions with base	14.8" x 7.1" x 14.9" (375mm x 180mm x 380mm)
weight set	8.2 lbs.
weight shipping	10.6 lbs.
tilt/swivel	Tilt: Forward 5° / Backward 20° (No Swivel)
vesa mounting compliance	75mm x 75mm Screw Spacing
