Symptom Check Point
1. Crush mode
doesn’t work
1. Check the loose connection
2. Check the resistance
8-12. Crush mode doesn’t work
Ice Maker Geared Motor Dispenser Motor
CON6
CON1
CON201
CON4
CON5
CON7
CON2 CON3
CON1
CON2
(BK)
(SB)
