LG LMXS28626 Series User Manual

- 6 -
1. Remove gasket
Pull gasket free from gasket channel on the four
remaining sides of door.
3-2 DOOR
●
Mullion Removal
1. Remove 2 screws.
●
Door Gasket Removal
2. Lift Mullion up carefully.
3. Disconnect wire harness.
●
Door Gasket Replacement
1. Insert gasket into channel
Press gasket into channels on the four remaining
sides of door.
2. Insert mullion into the channel.
Insert the cover assembly into bracket, door.
●
Mullion Replacement
1. Connect wire harness.
3. Assemble 2 screws.
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
Figure 7
Figure 8

LG LMXS28626 Series Specifications

General

Brand	LG
Model	LMXS28626 Series
Category	Refrigerator
Language	English
