LG LMXS28626 Series - Temperature Chart: Refrigerator and Defrost Sensor

- 44 -
10-3 TEMPERATRUE CHART - REF AND DEF SENSOR
TEMP
-39°F (-40°C)
-30°F (-35°C)
-21°F (-30°C)
-13°F (-25°C)
-4°F (-20°C)
5°F (-15°C)
14°F (-10°C)
23°F (-5°C)
32°F (0°C)
41°F (5°C)
50°F (10°C)
59°F (15°C)
68°F (20°C)
77°F (25°C)
86°F (30°C)
95°F (35°C)
104°F (40°C)
RESISTANCE
225.1 ㏀
169.8 ㏀
129.3 ㏀
99.30 ㏀
76.96 ㏀
60.13 ㏀
47.34 ㏀
37.55 ㏀
30 ㏀
24.13 ㏀
19.53 ㏀
15.91 ㏀
13.03 ㏀
10.74 ㏀
8.89 ㏀
7.40 ㏀
6.20 ㏀
VOLTAGE
4.48 V
4.33 V
4.16 V
3.95 V
3.734 V
3.487 V
3.22 V
2.95 V
2.67 V
2.40 V
2.14 V
1.89 V
1.64 V
1.45 V
1.27 V
1.10 V
0.96 V
