Single Zone High Efciency, Standard, Extended Pipe and Mega Wall Mount Installation Manual

Due to our policy of continuous product innovation, some specifications may change without notification.

ELECTRICAL WIRING

Single Zone Model Type Remote Controller Model

LS091HSV3, LS121HSV3 AKB73855712

LS181HSV3 AKB73855712

LS240HSV3 AKB73855713

LS307HV3, LS360HV3 AKB73855713

Single Zone Extended Pipe System

LS240HLV, LS300HLV, LS360HLV AKB74055401

Single Zone Mega System

LS090HEV, LS120HEV AKB73835305

LS180HEV, LS240HEV AKB73835305

Single Zone Mega 115V System

LS090HXV, LS120HXV

AKB73456121

Controllers

Refer to Table 31 as to which remote controller models to use for each Single Zone model types. Once all wiring is connected to the indoor

and outdoor units be sure to test the accompanying remote controllers for performance. As always, follow all safety warnings and notes when

operating the Single Zone units using the remote controller.

Table 31: Single Zone Models and Associated Remote Controller Model

Additionally, most of the Single Zone High Efficiency and Extended

Pipe outdoor models can use the following controllers when accom-

panied with the PI 485 VNet Accessory:

• AC Ez

• AC Smart Premium

• ACP

• BACnet®

• LonWorks®

• LGMV

Mega 115V is compatible with the following controllers:

• PREMTB10U

• PQDSB1

• PZCWR5C1

• LS091HSV3, LS121HSV3 models cannot use PI-485, or

the controller accessories.

• Single Zone Mega and Mega 115V systems cannot use PI-

485, or the controller accessories mentioned on this page.

They can use LGMV.
