- 30 -
8-3 RESISTANCE SPECIFICATION OF SENSOR
The resistance of the SENSOR has a ±5% common difference.
Temperature of the SENSOR must be stabilized for minimum of 3 minutes before accurate measurement can be taken
• Measure the F-SENSOR, SUPER FROST SENSOR, R1, R2-SENSOR after disconnect CON5 of PWB AS
TEMPERATURE
RESISTANCE OF REFRIGERATOR &
DEFROST SENSOR
VOLTAGE
-20 °C (-4 °F)
77
3.73
-15 °C (5 °F)
60
3.49
-10 °C (14 °F)
47.3
3.22
-5 °C (23 °F)
38.4
2.95
0 °C (32 °F)
30
2.67
5 °C (41 °F)
24.1
2.4
10 °C (50 °F)
19.5
2.14
15 °C (59 °F)
15.9
1.89
20 °C (68 °F)
13
1.66
25 °C (77 °F)
11
1.46
30 °C (86 °F)
8.9
1.27
40 °C (104 °F)
6.2
0.96
50 °C (122 °F)
4.3
0.72
To measure the outputs of the fans on the control boards check the voltages between the pins for the following components:
MOTOR ON MOTOR OFF
Freezer Fan Con 4 pin 5 Con 4 pin 6
10 - 14 VCD
2 VCD or less
Cooling Fan Con 4 pin 2 Con 4 pin 3 10 - 14 VCD 2 VCD or less
FAN PIN NUMBER PIN NUMBER
OUTPUT VOLTAGE
PIN 1 2 3 4 5 6 7 8 9 10
N/C G V F G V N/C N/C N/C N/C
C-FAN F-FAN N/C
CONNECTOR 4

LG LTCS20220W Specifications

General

Child lock	-
Door hinge	Right
Product color	White
Housing material	Metal, Stainless steel
Reversible doors	Yes
Shelves material	Tempered glass
Appliance placement	Freestanding
Noise level	- dB
Total net capacity	572 L
Total gross capacity	- L
Fridge net capacity	416 L
Fridge number of shelves/baskets	2
Freezer position	Top-placed
Freezing capacity	- kg/24h
Freezer net capacity	156 L
Storage time during power failure	- h
Connected load	- W
Annual energy consumption	406 kWh

Weight and Dimensions

Depth	838.2 mm
Width	736.6 mm
Height	1676.4 mm
Weight	91600 g
