- 7 -

Slightly lift up the refrigerator door and remove it.

Turn the freezer door upside down on a non-scratch surface.

Loosen the screw to remove the Door Closer/Stop and Hinge

Pin Insert.

Move the Hinge Pin Insert Bracket to the other side of the

door, keeping the same orientation, and move the Hinge Pin

Insert into the hole on the left side of the bracket.

Reverse the Door Closer/Stop by flipping it over. Place it on

top of the Hinge Pin Insert Bracket, and tighten both down with

the screw.

Middle Hinge Bracket

Hinge Pin

Fig. 19

Door Closer / Stop

Fig. 20

Hinge Pin

Insert Bracket

Hinge Pin Insert

Fig. 21

Fig. 22

Pry off the cover on the top left side of the refrigerator to

uncover the screw holes.

Set the freezer door and top hinge parts to the side and

remove the refrigerator door.

REVERSING THE REFRIGERATOR DOOR

Using a ¼” socket wrench, loosen and remove Hinge Pin from

the Middle Hinge Bracket. Remove washer underneath the

middle hinge and set aside.

NOTE: At this point the door will be loose. Slightly lift the door

and remove it.

Cover

(on top of

refrigerator)

Fig. 23

Fig. 29

Fig. 30

Questions and Answers:

Need help?

Do you have a question about the LG LTCS20220W and is the answer not in the manual?

LG LTCS20220W Specifications

General

Child lock	-
Door hinge	Right
Product color	White
Housing material	Metal, Stainless steel
Reversible doors	Yes
Shelves material	Tempered glass
Appliance placement	Freestanding
Noise level	- dB
Total net capacity	572 L
Total gross capacity	- L
Fridge net capacity	416 L
Fridge number of shelves/baskets	2
Freezer position	Top-placed
Freezing capacity	- kg/24h
Freezer net capacity	156 L
Storage time during power failure	- h
Connected load	- W
Annual energy consumption	406 kWh
