ENGLISH
103
EXTERNAL CONTROL DEVICE SETUP
24. 3D(Command: x t) (only 3D model)
Tochange3DmodeforMonitorset.
Transmission
[x][t][][SetID][][Data01][][Data02][][Data03][]
[Data04][Cr]
Data01
00:3DOn
01:3DOff
02:3Dto2D
03:2Dto3D
Data02
00:TopandBottom
01:SidebySide
02:CheckBoard
03:FrameSequential
Data03
00:RighttoLeft
01:LefttoRight
Data04
3DDepth:Min:0toMax:14
*Referto‘Realdatamapping’.Seep.102
*Ifdata1is00(3DOn),data4hasnomeaning.
*Ifdata1is01(3DOff)or02(3Dto2D),data2,data3
anddata4havenomeaning.
*Ifdata1is03(2Dto3D),data2anddata3haveno
meaning.
Data1 Data2 Data3 Data4
00 O O X
01 X X X
02 X X X
03 X X O
X:don'tcare
Acknowledgement
[t][][OK][Data01][Data02][Data03][Data04][x]
[t][][NG][Data01][x]
25. Extended 3D(Command: x v) (only 3D model)
Tochange3DmodeforMonitorset.
Transmission
[x][v][][SetID][][Data01][][Data02][Cr]
Data01:3Doption
00:3DPictureCorrection
01:3DDepth(2Dto3DOnly)
02:3DViewpoint
Data02Ithasownrangeforeach3Doption
determinedbyData01.
1)WhenData01is00
00:RighttoLeft
01:LefttoRight
2)WhenData01is01
DataMin:0toMax:14
3)WhenData01is02
DataMin:0toMax:14
DataMin:0toMax:06
*Referto‘Realdatamapping’.Seep.102
Acknowledgement
[v][][OK][Data01][Data02][x][v][][NG][Data01][x]
