Dimensions
- 42 -
Copyright © 2020 LG Electronics Inc.
All rights reserved. Only training and service purposes.
1. HR Units
Dimensions
CHASSIS CODE:
Outdoor Unit
PRHR042/PRHR042A
PRHR032/PRHR032A
PRHR022/PRHR022A
[Unit : mm(inch)]
76, Seongsan-dong, Changwon City, Gyeongnam,
641-713, Korea
480(18-29/32)
152(5-31/32)
345(13-19/32)
98(3-27/32)
481(18-15/16)
174(6-27/32)
453(17-27/32)204(8-1/32)
218(8-19/32)
38(1-1/2)
60(2-3/8)30(1-3/16)
