PREPARATION
PartsandComponents
This projector is manufactured using high-precision technology. You may,
however, see tiny black dots and/or bright colored dots (red, blue or green)
that continuously appear on the projector screen. This is a normal result of
the manufacturing process and does not indicate a malfunction.
MainUnit

Control panel
Lens
2
Vent
1
Speaker
Focus Ring
Button Description
(POWER)
Turns the projector on or off.
(SETTINGS)
Displays or closes the Settings menu.
, (CHANNEL) Changes the TV channel.
, (VOLUME)
Adjusts the volume level.
, , ,
Sets the function or moves the cursor.
(OK)
Shows the current mode and saves changes to
the settings.
1 Due to the high temperature of vent area, do not get close to the vent area.
2 Do not touch the lens when using the projector. The lens may be damaged.
