4-12
PIN NO. PIN NAME FUNCTION BLOCK
1 F2+ Outer Focus (+)
Actuator
2 F2- Outer Focus (-)
3 T+ Tracking (+)
4 F1+ Inner Focus (+)
5 T- Tracking (-)
6 F1- Inner Focus (-)
7 MOTOR_A- Step Motor A-
MOTOR
8 MOTOR_B- Step Motor B-
9 MOTOR_A+ Step Motor A+
10 MOTOR_B+ Step Motor B+
11 NC NC
NC12 NC NC
13 GND GND
14 A
Servo Signal Part
PDIC PART (BD/DVD_CD)
15 B
16 C
17 D
18 E
19 F
20 G
21 H
22 SW3 BD PD Sleep Selection
23 RF+ BD/DVD/CD RF+
24 RF- BD/DVD/CD RF-
25 SW2 BD PD Gain2
26 SW1 BD PD Gain1
27 VREF_2.1V PDIC Reference 2.1V
28 VCC_PD(5V) PDIC Power 5V
29 GND_PD PDIC GND
30 SW DVD/CD Sleep Selection
31 GND LD HFM GND
LD HFM IC Monitor
32 BD_LD LD Control BD
33 CD_LD LD Control CD
34 DVD_LD LD Control DVD
35 GND LD HFM GND
36 TEMP Thermistor
37 HFM_VCC(5V) HFM VCC
38 CD/DVD_MPD Monitor output DVD/CD
39 BD_MPD Monitor output BD
40 DVD_VR DVD Level adjust
41 CD_VR CD Level adjust
42 NC NC
43 5V_OUT PD Vcc Output
44 GND LD HFM GND
45 BD_VR BD Level adjust
3. PICK-UP CONNECTOR TERMINAL PIN ASSIGNMENTS
