2-73
ONE POINT REPAIR GUIDE
2. NO BOOTING WHEN YOU TURN THE UNIT ON, NO MESSAGE OR
“PLEASE WAIT” ON FRONT PANEL
When you turn on your set, it will blank / no message or “PLEASE WAIT” display on front panel, and
it will not boot-up.
2-6. IC504 (NAND FLASH MEMORY)
2-6-1. Solution
Replace IC504 on MAIN board.
2-6-2. How to troubleshoot (Countermeasure)
1) Please check physical status of IC504 on your eyes.
2) Check the VCC (3.3 V) of IC504 and if it’s normal, please replace IC504.
(Please make sure IC504 has proper program.)
3) After changing it, if the set is still not booting :
- Check DDR IC (IC502, IC503) refer to item 2-7.
- Check MT8560 IC (IC501) refer to item 2-8.
2-6-3. Service hint (Any picture / Remark)
< MAIN board bottom view >
IC501
IC502
IC503
IC504
To Next Page
