3-24
Copyright © 2021 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
ELECTRICAL TROUBLESHOOTING GUIDE
KEY PART
Replace the cables
Check R111 Pull-up Resistor
YES
Check CN103 1, 2 pin
Voltage 3.3 V
Check the connecting cables
Check RA01, RA04, RA05, RA06
Replace the Related part.
YES
NO
Check SWA01, SWA02,
SWA03, SWA04
OK
YES YES
NO
NO
OK
2. KEY PART
