LG SN4A - Usb

3-29
Copyright © 2021 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
4. USB
FIG 4-1. USB 5 V FIG 4-2. USB D+
8 9
FIG 4-3. USB D-
10
9
8
10
C205
10pF
NC
USB_GND
USB_5V
USB_5V
C206
10pF
NC
JK201
1
5V
2
USB D-
3
USB D+
4
DGND
D-
D+
202C
Fu01
302C
Fu01
C200
220uF
NC
DGND
102C Fn001
USB1_DP
USB1_DN
FB201
1
2
3
4
D201
uCLAMP0561P
R210 4.7
R211 4.7
USB
MPEG
