LG SP820 - Audio Output Specifications; Specifications

Appendix44
Appendix
5
Audio output specifications
Audio Input Digital Audio Output
AUTO
MPEG PCM
Dolby Digital Dolby Digital
Dolby Digital Plus Dolby Digital
HE-AAC Dolby Digital
PCM All PCM
Specifications
General
Power Supply
Refer to the main label or refer to the main label on the bottom.
Power consumption
AC adapter DA-18B12
Dimensions (W x H x D) Approx. 200 x 29 x 120 mm
Net Weight (Approx.) 0.51 kg
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Outputs
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector)
DIGITAL AUDIO OUT (OPTICAL) 3 V (p-p), Optical jack x 1
System
Signal system Standard PAL color TV system
LAN port Ethernet jack x 1, 10BASE-T / 100BASE-TX
Wireless LAN (internal antenna) IEEE 802.11b/g/n (2.4 GHz band)
Bus Power Supply (USB) DC 5 V
0
500 mA
�
Design and specifications are subject to change without notice.
