LG Therma V AHBW A0 Series Installation Manual

Installation
18 Air-to-Water Heat Pump
Water Pipe Insulation
Purpose of water pipe insulation is :
To prevent heat loss to external environment.
To prevent pipe breakage by freeze at winter season,
※ Must be insulation at exterior water pipe between product and building.
Shutoff Valve
- Shut-Off Valve is used to connect water pipe to unit.
- Tighten the flare nut with two spanner. (check the leak to the connection.)
When the water pipes are connected.
It must be tightened the nut with two wrench.
Otherwise pipes can be deformed.
Water In
Water Out
Union
WARNING
