PREPARATION
PREPARATION
Carefully place the TV screen side down
on a cushioned surface to protect the
screen from damage.
1
Assemble the TV as shown.
3
Assemble the parts of the Stand Rear
Cover with the TV.
4
Stand Rear
Cover
Fix the 4 bolts securely using the holes in
the back of the TV.
5
Assemble the parts of the Stand Body with
the Stand Base of the TV.
At this time, tighten the screws that hold the
Stand Body on.
2
Stand
Body
Stand
Base
M4 X 16
(Only 32/37/42/47LE55
**
,
32/37/42/47LE7
***
, 42/47LX6***)
M4 X 24
(Only 55LE55**,
55LE7***, 55LX6***)
M4 X 16
(Only
32/37/42/47/55LE55
**
,
32/37/42/47/55LE7
***
,
42/47/55LX6***)
M4 X 20
(Only 42/47/55LE8
***
)
M4 X 20
(Only 42/47/55LE8
***
)
Only 32/37/42/47/55LE55**, 32/37/42/47/55LE7***, 42/47/55LE8***, 42/47/55LX6***
■ Image shown may differ from your TV.
