A-22
PREPARATION
PREPARATION
Carefully place the TV screen side down
on a cushioned surface to protect the
screen from damage.
1
Assemble the TV as shown.
3
Assemble the parts of the Stand Rear
Cover with the TV.
4
Stand Rear
Cover
Fix the 4 bolts securely using the holes in
the back of the TV.
5
Assemble the parts of the Stand Body with
the Stand Base of the TV.
At this time, tighten the screws that hold the
Stand Body on.
2
Only 32/42/47/55LE4***
■ Image shown may differ from your TV.
Stand
Body
Stand
Base
M4 X 22(Only 32LE45
**,
32/42/47/55LE46**
)
M4 X 24 (Only 42LE45
**
)
M4 X 16
To Next Page
