51
VALVE
(STEAM:Option)
VALVE (
PRE-WASH)
VALVE
(NORMAL-WASH)
1
Disconnect the wiring connectors.
1
1
2
3
2
Disassemble the inlet valve by unfastening the
screws from the valve holder.
• Rating : 220/240V 50/60Hz
• Resistant : 3.5~4.5kΩ
2
When reconnecting the connector
1
Open the door completely.
2
Unfasten the screws from the door hinge.
3
Disassemble the door assembly by lifting it up
and then pulling it.
When removing the Door Assembly, it is
necessary to hold the Bracket that is inner of
the Cabinet Cover.
First, prepare a bucket to put the remaining
water in.
Drain from hose.
VIOLET/BLACK-BLACK
WHITE/BLACK-BLACK
GRAY/BLACK
INLET VALVE
3
DOOR ASSEMBLY
Removing method of remaining water
CAP(REMAING HOSE)
3
4
To Next Page
