LG WT1201C Series Service Manual

26
10) Disassembly of Door Lock Switch
① Remove the two door lock attachment screws.
② Remove the door switch and remove the attachment tube.
⑩ Remove 17 screws to release the bearing housing.
Pull the housing away from the tub, but do not pry it
with a screwdriver to avoid damage.
⑨ Remove four screws to release the tub bracket.
Bearing Housing

LG WT1201C Series Specifications

General

Style	Top-Loading
Color	Chrome
Washer Capacity	4.3 cu ft
Dryer Capactity	-
Max Spin Speed	1100 RPM
Spin Speeds	Low
Spin Class	C
Number of Cycles	8
Cycle Selections	Mixed 40°
Wash	Quick Wash
Options	ColdMotion technology
Hours	Extra Power / Boost Option
Noise level
Temperature Selections	Cold
Energy Class	-
Annual Energy Consumption	-
Annual Water Consumption	-
Water Consumption Per Cycle	-
Voltage	120 V
Frequency	-
Current	10 A

Weight and Dimensions

Depth	28 3/8 in
Height	40 5/32 in
Width	27 in
Net Weight	134.2 lbs
