56 Appendix 3 Installation Drawing
Liebert.CRV Series Air Conditioner User Manual
350
650 700
650
1175
550
2725
100
100
600
700
B
S
S
A
Service area is S + B or S + A
Figure 7 Service area (top view, unit: mm)
