Specifications
37
Table 13 Battery cabinet specifications
Parameter
Model Number
GXT3-48VBATT GXT3-72VBATT
Used w/UPS Model
GXT3-500RT120,GXT3-700RT120
GXT3-1000RT120,GXT3-1500RT120,
GXT3-2000RT120
GXT3-3000RT120
GXT3-3000RT208
Dimensions, D × W × H, in (mm)
Unit
19.7 x 16.9 x 3.3
(497 × 430 × 85)
23.7 x 16.9 x 3.3
(602 × 430 × 85)
Shipping
24.3 x 22.4 x 10.3
(617 x 570 x 262)
28.2 x 22.4 x 10.3
(717 x 570 x 262)
Weight, lb (kg)
Unit 57.3 (26) 83.8 (38)
Shipping 61.7 (28) 92.6 (42)
Battery parameters
Type Valve-regulated, nonspillable, lead acid
Qty × V× Rating 2 × 4 × 12V × 9.0Ah 2 × 6 × 12V × 9.0Ah
Battery Mfr./Part # Panasonic/UP-RW1245; CSB/HR 1234W F2
Backup Time See Table 15
Environmental
Operating Temperature, °F (°C) 32 to 104 (0 to 40)
Storage Temperature, °F (°C)
19 to 122 (-15 to 50)
High ambient temperatures will reduce battery life.
Relative Humidity 0% to 95%, non-condensing
Operating Elevation Up to 10,000 ft. (3000m) at 104ºF (40ºC) without derating
Storage Elevation 50,000 ft. (15000m) maximum
Agency
Safety UL 1778, c-UL Listed
RFI/EMI FCC Part 15, Class A=CISPR22 Class B
Surge Immunity IEC 62040-2 2nd Ed
Transportation ISTA Procedure 1A
Table 14 Operating temperature parameters
Ambient Temperature, °C (°F) 25-30 (77-86) 30-35 (86-95) 35 - 40 (95-104)
Maximum Output
Power Factor Derating
@ Maximum Load
100%-93% 93%-86% 86%-79%
