Liebert PowerSure PSA - Rear View of UPS

6
Rear View of UPS
6-ft. (1.8m)
power cord
Input circuit
protector
Orange output
receptacles*
Battery backup +
surge protection
Black output
receptacles (2)*
Surge protection
only
Site Wiring Fault
Indicator (Red)**
Data Line Protection
Connectors (2)***
Phone/Fax/DSL/Internet/
Modem devices
Battery cover plate
(on rear of 350 & 500VA
models)
350&500VA
Models
6-ft. (1.8m)
power cord
Input circuit
protector
Orange output
receptacles*
Battery backup +
surge protection
NOTE: Two top
receptacles
included on
1000VA models
only
Black output
receptacles (2)*
Surge protection
only
Site Wiring Fault
Indicator (Red)**
Data Line Protection
Connectors (2)***
Phone/Fax/DSL/Internet/
Modem devices
For details, see:
* Installation section
** Controls and Indicators section
*** Communications section
Battery cover plate
(bottom of unit for
650&1000VA models)
650&1000VA
Models
DB-9
port***
USB
port***
DIP
switches**
DB-9
port***
USB
port***
DIP
switches**
