DOWNFLOW CHILLED WATER MODELS
Form No.: DPN001040_REV4
PRIMARY CONNECTION LOCATIONS
LIEBERT PCW
A
A
34 1/2"
876mm
32 15/16"
837mm
FRONT OF UNIT
HWS
HWR
LV1
LV2
FRONT OF UNIT
E4
E3
LV3
SECTION B-B
X
Y
O
TOP VIEW
X
Y
O
SECTION A-A
BOTTOM CONNECTIONS
FRONT VIEW
28 9/16"
725mm
30 1/2"
775mm
WS
WR
POINT DESCRIPTION X in. (mm) Y in. (mm) CONNECTION SIZE / OPENING
HWR HOT WATER REHEAT RETURN (OPTIONAL) 7-5/8 (194)
HWS HOT WATER REHEAT SUPPLY (OPTIONAL) 11-3/4 (298)
WS WATER SUPPLY 24-3/4 (629)
WR WATER RETURN 27-3/8 (695)
CD CONDENSATE DRAIN 21-1/4 (540) 3/4" NPT FEMALE
CE CONDENSATE ELECTRICAL 24 (610) 1-1/2"
HUM HUMIDIFIER SUPPLY LINE 32 (813) 30-1/8 (765) 1/4"
E1 ELECTRICAL CONN. (HIGH VOLT) BOTTOM 28-3/8 (721)
E2 ELECTRICAL CONN. (HIGH VOLT) BOTTOM 26-1/8 (664)
E3 ELECTRICAL CONN. (HIGH VOLT) TOP 27-5/8 (701)
E4 ELECTRICAL CONN. (HIGH VOLT) TOP 29-7/8 (758)
LV1 ELECTRICAL CONN. (LOW VOLT) BOTTOM 2-3/4 (70) 30-1/8 (765) 1-1/8"
LV2 ELECTRICAL CONN. (LOW VOLT) BOTTOM 3-1/2 (89) 29 (737) 1-1/2"
LV3 ELECTRICAL CONN. (LOW VOLT) TOP 31-5/8 (803) 24-7/8 (632) 1"
2-7/8 (73)
31-1/2 (800)
31-1/4 (793)
5/8"
1-1/8"
7/8”, 1-3/8”, 1-3/4”
31-1/2 (800)
B B
SUPPLY AIR
DISCHARGE OPENING
ELECTRICAL TOP
CONNECTIONS
Note:
1. Drawing not to scale. All dimensions from rear corner of unit including panels, and have a tolerance of ± 1/2" (13mm).
2. Field pitch Condensate drain line a minimum of 1/8" (3mm) per 12" (305mm). All units contain a factory installed condensate trap. Do not trap
external to the unit. Drain line may contain boilng water. Select appropriate drain system materials. The drain line must comply with local codes.
3. All water piping is O.D. Copper except as noted.
2
CE
CD
E2
E1
HUM
1
1
2
