REV : 7
REV DATE : 12/16
DPN002971
Page :2 /2
Form No.: DPN001040_REV4
LIEBERT PDX & PCW
UPFLOW REAR RETURN
FLOORSTAND
31 5/8"
804mm
32 5/8"
829mm
Note:
1. Leveling feet are provided with +/- 1-1/2" (38mm) adjustment from nominal height.
2. Rear Duct Flange connection is 1" (25mm) deep.
FRONT VIEW
REAR VIEW
FILTER
1"
25mm
DUCT FLANGE OPENING
DUCT
FLANGE
OPENING
28 7/8"
734mm
14 3/4"
375mm
3"
76mm
O
7/8"
23mm
24"
610mm
DUCTWORK FLANGE
19 5/8"
498mm
7 3/8"
187mm
Nominal
Height
1
34"
864mm
24"
610mm
Shaded area indicates a
required minimum
clearance for filter removal,
includes any nonremovable
floor supports.
Recommended Clearance for
unit installation and for servicing
these components if equipped:
Reheat, Filter Clog Switch,
Econ-O-Coil Valve, or Gravity Drain
Connections.
DIMENSIONAL DATA
