MAIN WALL CONTROLS
3-Speed Control (99-500) Operation:
(1) High Speed Fan
(2) Medium Speed Fan
(3) Low Speed Fan
Press the applicable Fan Speed button to set the fan speed. Press the
applicable OFF button in order to turn the Fan Speed control off.
3-Speed Control (99-500) Installation:
Connect the wires to the R, W, Y, and G terminals on the Aircom circuit board as shown.
• Use 4 wire; 20-gauge wire (minimum)
• When used in conjunction with the 99-BC02, the BC02 control must be ON for the 99-500 control
to operate. The 99-BC02 will override the 99-500 control when the Dehumidistat is operating or the
control is set to HIGH speed
