TIMERS AND REPEATERS
99-RX02 Repeater
(1) Green LED
(2) Red LED
(3) Power Plug
The wireless repeater is used to extend the range of the 99-DET02 wireless
timers. The repeater plugs directly into a 120V power outlet. The 99-RX02
repeater wirelessly connects to the main wall control as well as the 99-DET02
wireless timers.
The 99-RX02 repeater should be installed at the halfway point between the 99-
DET02 wireless timer and the main wall control if the timer is out of range. The LED will indicate the repeater’s
connection strength to the main wall control per the table below. Re-adjust the repeater’s position as
necessary.
No further adjustments are required.
The repeater will function properly but shouldn’t be moved further
away from the main control.
The repeater needs to be moved closer to the main control.
Pairing:
1. Turn on the main control by pressing the ON/OFF button .
2. BC02, BC03 or BC04 control: Press the left and right buttons simultaneously on the main control
( and or ). The bottom row LED's will begin flashing. This indicates that the main control is
now in pairing mode.
3. The RX02 Repeater must be powered within 16 in. of the main control for pairing. If an outlet is not
available an extension cord should be used to power the Repeater initially for pairing.
4. Plug the repeater into the power outlet. The green light will flash after approximately 12 seconds
indicating that the repeater is paired with the main control.
5. Press the ON/OFF button on the main control to exit pairing mode and the repeater may now be
unplugged and moved to its permanent location.
6. To pair additional repeaters with the same main control, repeat steps 1 through 5 until all repeaters
have been paired.
• The repeaters are to be plugged directly into a 120V power outlet.
