27 AIRFLOW CHARTS (RNC88)
The RNC4-TPD units have three airflow charts for their installer adjustable high speed settings. Refer to
Installer Selectable High Speed Settings in this manual for instructions on how to adjust the circuit board DIP
switches.
Hi 3
Hi 2
Hi 1
Pressure
Drop
Supply
Airflow
Exhaust
Airflow
Pressure
Drop
Supply
Airflow
Exhaust
Airflow
Pressure
Drop
Supply
Airflow
Exhaust
Airflow
(“w.g.)
(Pa)
(cfm)
(cfm)
(“w.g.)
(Pa)
(cfm)
(cfm)
(“w.g.)
(Pa)
(cfm)
(cfm)
0.010
2
21
25
0.010
2
18
21
0.010
2
18
21
0.015
4
25
29
0.015
4
22
25
0.015
4
22
24
0.020
5
28
32
0.020
5
25
28
0.020
5
25
28
0.025
6
32
35
0.025
6
29
32
0.025
6
29
31
0.030
7
36
38
0.030
7
33
35
0.030
7
33
35
0.035
9
39
41
0.035
9
37
39
0.035
9
37
38
0.040
10
43
45
0.040
10
40
42
0.040
10
41
42
0.045
11
46
48
0.045
11
44
45
0.045
11
45
45
0.050
12
50
51
0.050
12
48
49
0.050
12
48
49
0.055
14
53
54
0.055
14
52
52
0.055
14
52
52
0.060
15
57
58
0.060
15
56
56
0.060
15
56
56
0.065
16
60
61
0.065
16
59
59
0.065
16
60
59
0.070
17
64
64
0.070
17
63
63
0.070
17
64
63
0.075
19
68
67
0.075
19
67
66
0.075
19
68
66
0.080
20
71
71
0.080
20
71
70
0.080
20
71
70
0.085
21
75
74
0.085
21
75
73
0.085
21
75
73
0.090
22
78
77
0.090
22
78
76
0.090
22
79
77
0.095
24
82
80
0.095
24
82
80
0.095
24
83
80
0.100
25
85
84
0.100
25
86
83
0.100
25
87
84
0.105
26
89
87
0.105
26
90
87
0.105
26
91
87
0.110
27
92
90
0.110
27
94
90
0.110
27
95
91
0.115
29
96
93
0.115
29
97
94
0.115
29
98
94
0.120
30
100
97
0.120
30
101
97
0.120
30
102
98
0.125
31
103
100
0.125
31
105
100
0.125
31
106
101
0.130
32
107
103
0.130
32
109
104
0.130
32
110
105
0.135
34
110
106
0.135
34
113
107
0.135
34
108
0.140
35
114
110
0.140
35
111
0.145
36
117
113
0.150
37
121
116
0.155
39
119
