Lifebreath RNC5 HEX TPF User Manual

lifebreath.com 47
34 AIRFLOW CHARTS (RNC200)
Door port balancing on the RNC200 can be achieved by using the following chart.
Balance this unit on its factory circuit board DIP switch setting (Hi 3)
RNC200
Reading
from
Manometer
Airflow
Numbers
Pressure
Drop
Supply
Airflow
Exhaust
Airflow
(“w.g.)
(Pa)
(cfm)
(cfm)
0.100
24.9
98
91
0.110
27.4
102
96
0.120
29.9
107
101
0.130
32.4
111
107
0.140
34.9
115
112
0.150
37.4
120
117
0.160
39.9
124
122
0.170
42.4
128
127
0.180
44.9
133
132
0.190
47.3
137
137
0.200
49.8
141
142
0.210
52.3
145
147
0.220
54.8
149
152
0.230
57.3
153
156
0.240
59.8
157
161
0.250
62.3
161
166
0.260
64.8
165
171
0.270
67.3
169
175
0.280
69.8
173
180
0.290
72.3
177
184
0.300
74.8
181
189
0.310
77.2
185
193
0.320
79.7
189
198
0.330
82.2
192
202
0.340
84.7
196
207
0.350
87.2
200
211
0.360
89.7
203
215
