6 MOUNTING (RNC4-TPD, RNC4-TPF, & RNC 88)
Mounting the RNC4-TPD & RNC4-TPF:
(1) Mounting Points
1. Locate the four mounting tabs on the left and right sides of the unit, at the front and back.
2. Using a flat head screwdriver, bend out the four tabs to approximately 45 degrees.
3. Once the tabs have all been bent outwards, insert the “S” hooks through the four holes on the tabs.
4. Install the unit to the structure. Refer to Hanging Straps.
Mounting the RNC 88:
(1) Mounting Points
1. Mounting locations on RNC 88 uses standard mounting hardware, same as other RNC HRVs.
2. Install the unit to the structure. Refer to Hanging Straps.
•
Do not drill additional holes in the HRV
